Xinxian technology integrates R & D, production and sales, and is engaged in LCD and LCD module

Provide one-stop professional services!

Tel:0755-2640 2953 Online consultation
size model power
(H*V)		 brightness Voltage
(V)		 Clock and buzzer Voice function data remarks
4.3寸 AS(G)043FCA01R 480*272 250/300 5-15V Clock, voice, buzzer Serial screen TTL/232
5寸 AS(G)050SCA01R 480*272 250/300 5V-15v Clock, voice, buzzer Serial screen TTL/232
7寸 AS(G)070YCA02R 800*480 250/300 5-15V Clock, voice, buzzer Serial screen TTL/232
8寸 AS(G)080SCA01R 800*600 250/300 5V-15V Clock, voice, buzzer Serial screen TTL/232
9.7寸 AS(G)097XTB01R 1024*768 250/300 12V-24V Clock, voice, buzzer Serial screen TTL/232
10.1寸 AS(G)101LTB01R 1024*600 250/300 5V-15V Clock, voice, buzzer Serial screen TTL/232
10.4寸 AG104LTB01R 800*600 250/300 5V-15V Clock, voice, buzzer Serial screen TTL/232
15寸 AS(G)150TA01R 1024*768 250/300 9V-15V Clock, voice, buzzer Serial screen TTL/232

Car tire pressure monitoring screen

characteristic：

View Contact
Car tire pressure monitoring screen

Thermostat VA screen

characteristic：

View Contact
Thermostat VA screen

Speedometer LCD screen

characteristic：

View Contact
Speedometer LCD screen

Car dashboard LCD liquid crystal display

characteristic：

View Contact
Car dashboard LCD liquid crystal display

Elevator special LCD liquid crystal display

characteristic：

View Contact
Elevator special LCD liquid crystal display
Thermostat VA screen
Thermostat VA screen
Speedometer LCD screen
Speedometer LCD screen
Car dashboard LCD liquid crystal display
Car dashboard LCD liquid crystal display
character
WxH		 series appearance
WxH(mm)		 window
WxH(mm)		 model
 Voltage Interface type information
08*02 0802B series 58*32 22.8*9.6 ST7066 3.3V or 3.5V Parallel
16*01 1601A series 80*36 64.6*16.0 ST7066 3.3V or 5V Parallel or Serial
16*02 1602A series 80*36 64.6 * 16.0 ST7066 3.3V or 5V Parallel or Serial
16*02 1602C series 84*44 64*16 ST7066 3.3V or 3.5V Parallel or Serial
20*02 2002A series 116*37 83*18.6 ST7066 3.3V or 3.5V Parallel or Serial
20*04 2004A series 98*60 76*25.2 ST7066 3.3V or 5V Parallel or Serial
40*02 4002A series 182*33.5 155.4*15.8 ST7066 3.3V or 3.5V Parallel or Serial
40*04 4004A series 190*54 149*23.5 ST7066 3.3V or 3.5V Parallel or Serial
number
WxH		 Family overall
WxH(mm)		 window
WxH(mm)		 controller
或兼容型号		 voltage interface type data
192*64 19264C series 130*65 104*39 S6B0107 3.3V or 5V parallel port
192*64 19264B series 120*62 104*39 S6B0107 3.3V or 5V Parallel or Serial
192*64 19264A series 100*60 84*31 S6B0107 3.3V or 5V Parallel or Serial
160*32 16032 series 122*44 99*24 ST7920 3.3V or 3.5V Parallel or Serial
128*64 12864K series 93*70 72*39 ST7920 3.3V or 3.5V Parallel or Serial
128*64 12864M series 78*70 62*44 ST7920 3.3V or 3.5V Parallel or Serial
128*64 12864 series 75*52.7 60*32.5 S6B0107 3.3V or 3.5V Parallel or Serial
128*64 12864C series 93*70 72.0*39.0 S6B0107 3.3V or 3.5V Parallel or Serial
128*64 12864B series 78*70 62*44 S6B0107 3.3V or 3.5V Parallel or Serial
128*64 12864A series 113*65 7736*24.8 S6B0107 3.3V or 3.5V Parallel or Serial
128*32 12832 series 110*65 77.6*24.8 S6B0107 3.3V or 3.5V Parallel or Serial
122*32 12232E series 76.5*29.0 60*21 S6B0107 3.3V or 3.5V Parallel or Serial
122*32 12232AZK 84*44 60*18 ST7920 3.3V or 3.5V Parallel or Serial
122*32 12232B series 80*36 61*20 S6B0107 3.3V or 3.5V Parallel or Serial
inch model resolution overall dimension display area connection mode brightness drive IC remarks
7.0 7.0"TFT 800*480 RGB compatible
5.0 5.0" TFT 480*272 120.70*62.83 RGB+RTP HX8257A
4.5 4.5" TFT 480*854 125.00*68.90 MIPI 2L+CTP ILI9806E
4.3 4.3" TFT 480*272 105.4*67.10 RGB ST7282/NV3047
4.0 4.0" TFT 480*800 96.85*51.84 SPI+RGB
3.5 3.5" TFT 320*480 84.74*54.48 MCU8/16BIT/SPI+RGB ILI9488
3.2 3.2" TFT 240*320 77.70*54.34 MCU ILI9341V
3.0 3.0" TFT 360*640 74.91*43.04 SPI+RGB/MIPI ST7701S
2.8 2.8" TFT 240*320 69.20*50.00 SPI+RGB ILI9341V
2.4 2.4" TFT 240*320 60.26*42.72 SPI ST7789V
2.0 2.0" TFT 240*320 51.30*36.05 SPI ST7789V
1.77 1.77" TFT 128*160 43.70*34.00 SPI ST7735S
1.54 1.54" TFT 240*240 33.72*30.52 SPI ST7735S
1.44 1.44" TFT 128*128 36.50*30.90 SPI ST7735S

Backlight

features：

View Contact
Backlight

Backlight

features：

View Contact
Backlight

Backlight

features：

View Contact
Backlight

Backlight

features：

View Contact
Backlight

Backlight

features：

View Contact
Backlight
Backlight
Backlight
Backlight
Backlight
Backlight
Backlight

capacitance

features：

View Contact
capacitance

resistance

features：

View Contact
resistance

chip

features：

View Contact
chip
resistance
resistance
chip
chip
